SHIMANO - HYPERDRIVE - Trail MTB Crankset - 3x9-speed
The SHIMANO FC-MT101 crank is designed for 3x9 speed MTB drivetrains. With HYPERDRIVE technology it provides smooth and precise shifting.
- Smooth and precise shifting performance for trail focused riders
- HYPERDRIVE
PRODUCT SPECIFICATIONS
| MODEL NO | FC-MT101 |
|---|---|
| SERIES | ALTUS M2000 Series |
| Color | Black |
| Remarks | SHIMANO logo |
| Axle length of BB-UN/ES (mm)_Threaded (normal) | LL123 |
|---|---|
| Chain line (mm) | 50 |
| Chainring combination | 44-32-22T 40-30-22T |
| Compatible bottom bracket type_Square | ✔ |
| Compatible chain | HG 9-speed |
| Crank fixing bolt included | X (Option) |
| Crank arm length (mm)_170 | ✔ |
| Crank arm length (mm)_175 | ✔ |
| Spider/Gear arms | 4 |
| Optional chain guard_With chain guard | ✔ |
| Optional chain guard_Without chain/bash guard | ✔ |
| P.C.D. (mm) | Riveted |
| Rear speeds | 9 |
| Recommended bottom bracket_Threaded (normal) | BB-UN101 |
| Threaded bottom bracket shell width (mm)_68 | ✔ |
| Threaded bottom bracket shell width (mm)_73 | ✔ |
| Q-factor (mm) | 179.2 |
| Chain line (mm) | 50 |
| Compatible chain | HG 9-speed |
| P.C.D. (mm) | Riveted |
| Rear speeds | 9 |
| O.L.D._QR/Nut (mm) | 135 |
| O.L.D._Thru (mm) | 142 |
